High Frequency Induction Heater (HF-80KW)

Payment Terms : L/C,D/A,D/P,T/T

Model NO. : HF-80KW

Transport Package : Wooden Box

Input Current : 73A

Origin : China

Price : 3980

Production Capacity : 10, 000sets

Supply Ability : 1000/month

Work Voltage : 220V, 380V, 400V, 415V,440V, 480V*3phase 50-60Hz

Model Number : HF-40KW

Specification : CE, SGS, ISO

Delivery Time : 3days

Frequency : 30-80kHz

Type : IGBT

Packaging Details : ply wooden box package

Power : 48kw

MOQ : 1

Certification : CE/SGS/ROHS

Place of Origin : CHINA

HS Code : 8514400090

Application : Heating, Quenching, Forging, Melting, Welding

Brand Name : OURUIDA

Trademark : ORD

Contact Now

HF-80KW High Frequency Induction Heating Machine:
High Frequency Induction Heater (HF-80KW)

Advantage:
1 More than 26 years experience,stable and goods performance
2 CE certificated
3 Copperated with ZHOUDAFU, Matsushita,Foxconn, Media, Gree a6nd ZHIGAO Air conditioner.
4 Suitable for a large range, heating, quenching, forging, melting, solding and so on.
5 Two transformer ratios, can match better different length induction coil

Main characteristics:
1 IGBT module and Inverting technologies of third generation been used; Higher reliability and lower maintenance cost.
2 100% Duty cycle, continuous working is allowed at maximum power output.
3 Display of heating power and heating current and oscillating frequency;
4Â Simple to install, Installation can be done by unprofessional person very easily;
5Â Light weight
6Â Advantages of the model with timer: The power and the operating time of the heating period and the retain period can be preset respectively, to realize a simple heating curve, this model is suggested to use for batch production to improve the repeatability;
7Â Constant current or constant power status can be selected accordingly to achieve higher heating efficiency;

High Frequency Induction Heater (HF-80KW)High Frequency Induction Heater (HF-80KW)
High Frequency Induction Heater (HF-80KW)

High Frequency Induction Heater (HF-80KW)
High Frequency Induction Heater (HF-80KW)
High Frequency Induction Heater (HF-80KW)

 Type HF-80AB
 Work Power  3*380v/415v/440v/480v 50-60hz
 The range of operating voltage  340-430V AC
 Output power  80KW
 Input current  73A
 Fluctuating frequency  30-80khz
 Timing (Heat time,Retain time,Cool time)  1-99S
 The flow rate of cooling water  0.15 Mpa 11L/Min
 Water temperature protection point  40centidegree
 Duty cycle  100% (40degree room temperature)
 Weight  Mainparts:55Kg   Transformer:51kg
 Size Main Parts:640*280*550MM
Transformer: 510*260*410MM

High Frequency Induction Heater (HF-80KW)High Frequency Induction Heater (HF-80KW)
High Frequency Induction Heater (HF-80KW)High Frequency Induction Heater (HF-80KW)
